12B-1-12-NKZ/D20 (3/4 × 7/16) - 12 Teeth, with Hub, Hardened Teeth, 2 Screws, Bore 20H7, Keyway (Steel)

Sprocket

Price for you :

Price without VAT: 10.58

Price including VAT: 12.81 with VAT

Catalogue price excluding VAT:
10.79

At supplier, we usually ship within 2 weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.

Sprocket Parameters

Type: 12B-1
Diameter d0 (mm): 73.60 Diameter d0
Pitch diameter of the sprocket.
No. of teeth: 12
Width H (mm): 35.00 Width H
Overall width of the sprocket, including the hub. For sprockets with a finished bore and hardened teeth, it is commonly denoted as H.
Bore D (mm): 20.00 Bore D
Diameter of the finished bore with H7 tolerance, with keyway. For sprockets with a finished bore and hardened teeth, it is commonly denoted as D.
Brand: - Brand: -
This standardized product may come from different manufacturers. We will provide you with the currently supplied brand upon request.
Material: Steel Material
In the TYMA Product Catalogues you can find this material also described with the abbreviation ST.
Weight (kg): 0.670

Sprocket Description

12B-1-12-NKZ/D20 (3/4 × 7/16) - 12 Teeth, with Hub, Hardened Teeth, 2 Screws, Bore 20H7, Keyway (Steel) sprockets are ready for immediate installation on the appropriate shaft without the need for additional machining. They are designed for drives with all types of 12B-1 (3/4″ × 7/16″) simplex roller chains of the so-called European series (B-series), standardized to ISO 606 (DIN 8187).

The bore with a keyway ensures precise mounting and effective power transmission. The keyway, cut with a P9 tolerance (according to DIN 6885/1), is aligned with the tooth center, allowing for paired sprocket mounting. The bore is prepared with a tolerance field of H7. Additionally, the hub is equipped with two threaded holes and set screws for precise shaft fixation. One hole is aligned with the keyway, while the other is positioned 90° offset.

Sprocket Fields of Use

Finished sprockets in use

12B sprockets with a finished bore, hub, and hardened teeth for DIN 8187 roller chains are designed for a wide range of industrial applications – from light to heavy industry.

They are most commonly used in power transmission systems, but they also find applications in lifting and material transport systems. Typical fields of use include conveyors, food processing machines, and glassmaking equipment, as well as many other industrial applications.

Sprocket Material

C45E steel (according to UNI EN 10083-1).

Documents for Download

Dimensions and Parameters of Hardened Teeth Sprockets with Finished Bore - Preview

Dimensions and Parameters of Hardened Teeth Sprockets with Finished Bore

TYMA CZ Data Sheets

Czech and English (PDF 1.39 MB)

Chains - Preview

Chains

TYMA CZ Catalogue

Czech (PDF 2.01 MB)

Sprockets and Plate Wheels - Preview

Sprockets and Plate Wheels

TYMA CZ Catalogue

Czech and English (PDF 3.77 MB)
