CONTI SYNCHROFORCE EXTREME Timing Belts
High performance timing belts CONTI SYNCHROFORCE EXTREME in HTDHigh Torque Drive
Because of its tooth height and semi-circular tooth geometry, the HTD profile is especially good at avoiding jump-over of the teeth in operation. The HTD profile is extremely suitable for transmitting high torques. and CTDConti Torque Drive
The CTD profile is a symbiosis of the HTD and STD profiles, combining the benefits of both tooth geometries. The tooth height and width correspond to that of the HTD profile for transmitting extremely high torques and preventing jump-over at the same time, while the involute-shaped flank ensures very smooth running. profile are intended for the transmission of the highest performance and forces in drives with the highest torques. They are manufactured according to ISO 9563.
The belts are made of a special HNBRHydrogenated Nitrile (Acrylonitrile) Butadiene Rubber compound and glass cord tension member. To deal with the impact loads occurrring in the case of abrupt acceleration and deceleration, the compound is highly resistant to elongation and tearing. It reliably absorbs even maximum surges and guarantees the maintenance-free functioning of the belt in continuous service. A specially finished fabric provides top wear and abrasion resistance.
Products are sorted by name in ascending order.
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-966-85 EXTREME CONTI SYNCHROFORCE
Timing Belt
At Supplier
Within 3 Weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.
We usually made this product from a semi-finished product during the first working day after the order.
714.55€ excl. VAT
864.61€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-1190-115 EXTREME CONTI SYNCHROFORCE
Timing Belt
At Supplier
Within 3 Weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.
We usually made this product from a semi-finished product during the first working day after the order.
1,047.05€ excl. VAT
1,266.93€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-1190-55 EXTREME CONTI SYNCHROFORCE
Timing Belt
At Supplier
Within 2 Weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.
500.76€ excl. VAT
605.92€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-1190-85 EXTREME CONTI SYNCHROFORCE
Timing Belt
At Supplier
Within 3 Weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.
We usually made this product from a semi-finished product during the first working day after the order.
773.91€ excl. VAT
936.43€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-1400-170 EXTREME CONTI SYNCHROFORCE
Timing Belt
At Supplier
Within 3 Weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.
We usually made this product from a semi-finished product during the first working day after the order.
1,678.47€ excl. VAT
2,030.94€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-1400-40 EXTREME CONTI SYNCHROFORCE
Timing Belt
At Supplier
Within 3 Weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.
We usually made this product from a semi-finished product during the first working day after the order.
394.93€ excl. VAT
477.87€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-1400-55 EXTREME CONTI SYNCHROFORCE
Timing Belt
At Supplier
Within 3 Weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.
We usually made this product from a semi-finished product during the first working day after the order.
543.03€ excl. VAT
657.07€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-1400-85 EXTREME CONTI SYNCHROFORCE
Timing Belt
At Supplier
Within 3 Weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.
We usually made this product from a semi-finished product during the first working day after the order.
839.23€ excl. VAT
1,015.47€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-1610-40 EXTREME CONTI SYNCHROFORCE
Timing Belt
In Stock We update the stock availability information every 2 hours.
The goods we have in stock are usually ready for shipping or personal collection no later than the next working day. In case of personal collection, please do not come to pick the goods up before we contact you that the goods are ready.
425.11€ excl. VAT
514.38€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-1610-50 EXTREME CONTI SYNCHROFORCE
Timing Belt
In Stock We update the stock availability information every 2 hours.
The goods we have in stock are usually ready for shipping or personal collection no later than the next working day. In case of personal collection, please do not come to pick the goods up before we contact you that the goods are ready.
531.38€ excl. VAT
642.97€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-1610-55 EXTREME CONTI SYNCHROFORCE
Timing Belt
In Stock We update the stock availability information every 2 hours.
The goods we have in stock are usually ready for shipping or personal collection no later than the next working day. In case of personal collection, please do not come to pick the goods up before we contact you that the goods are ready.
584.52€ excl. VAT
707.27€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-1610-85 EXTREME CONTI SYNCHROFORCE
Timing Belt
In Stock We update the stock availability information every 2 hours.
The goods we have in stock are usually ready for shipping or personal collection no later than the next working day. In case of personal collection, please do not come to pick the goods up before we contact you that the goods are ready.
903.35€ excl. VAT
1,093.05€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-1778-85 EXTREME CONTI SYNCHROFORCE
Timing Belt
At Supplier
Within 2 Weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.
972.14€ excl. VAT
1,176.28€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-1890-115 EXTREME CONTI SYNCHROFORCE
Timing Belt
At Supplier
Within 3 Weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.
We usually made this product from a semi-finished product during the first working day after the order.
1,358.54€ excl. VAT
1,643.84€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-1890-40 EXTREME CONTI SYNCHROFORCE
Timing Belt
At Supplier
Within 3 Weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.
We usually made this product from a semi-finished product during the first working day after the order.
472.54€ excl. VAT
571.77€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-1890-85 EXTREME CONTI SYNCHROFORCE
Timing Belt
At Supplier
Within 3 Weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.
We usually made this product from a semi-finished product during the first working day after the order.
1,004.14€ excl. VAT
1,215.01€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-2100-40 EXTREME CONTI SYNCHROFORCE
Timing Belt
At Supplier
Within 3 Weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.
We usually made this product from a semi-finished product during the first working day after the order.
506.09€ excl. VAT
612.36€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-2100-55 EXTREME CONTI SYNCHROFORCE
Timing Belt
At Supplier
Within 3 Weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.
We usually made this product from a semi-finished product during the first working day after the order.
695.87€ excl. VAT
842.00€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-2100-85 EXTREME CONTI SYNCHROFORCE
Timing Belt
At Supplier
Within 3 Weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.
We usually made this product from a semi-finished product during the first working day after the order.
1,075.44€ excl. VAT
1,301.28€ incl. VAT
Antistatic – for compliance with requirements to ISO 9563.
HTD 14M-2310-40 EXTREME CONTI SYNCHROFORCE
Timing Belt
At Supplier
Within 3 Weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.
We usually made this product from a semi-finished product during the first working day after the order.
349.52€ excl. VAT
422.92€ incl. VAT
Products are sorted by name in ascending order.
Belts Construction
- Specially finished fabric
- Synthetic rubber teeth HNBR
- Glass cord tension member
- Synthetic rubber backing HNBR
Belts Fields of Use
The CONTI SYNCHROFORCE® EXTREME timing belts are the most durable and powerful rubber timing belts. They are used in transmissions with high shock loads, highest torques and acceleration.
They are typically used in machine tools, presses, textile machines, printing machines, in the automotive industry and many other machines.
Belts Characteristics
- High transmission power and long life
- Suitable for tropical climates
- Temperature range, depending on application, from −30 °C to +130 °C
- Antistatic in accordance with ISO 9563
- Maintenance-free
- Suitable for reverse flexing
Belts Code Description
Example:
HTD 14M-2100-40 EXTREME CONTI SYNCHROFORCE
| Code Part | Description |
|---|---|
| HTDHigh Torque Drive Because of its tooth height and semi-circular tooth geometry, the HTD profile is especially good at avoiding jump-over of the teeth in operation. The HTD profile is extremely suitable for transmitting high torques. |
Profile |
| 14M |
Tooth pitch in mm |
| 2100 |
Belt length in mm |
| 40 |
Belt width in mm |
| EXTREME CONTI SYNCHROFORCE |
Type of belt |
Notice
CONTI SYNCHROFORCE EXTREME timing belts are available in HTD 14M and CTD C14M profiles.
Belts Certification
- Factory Electrical Conductivity Certificate of Belts According to ISO 1813 and ISO 9563 (pdf, 104.90 kB)
- ContiTech Explanation of ATEX Certification (pdf, 11.96 kB)
Notice
General factory certificates are not sufficient for belts used in potentially explosive atmospheres.
If a test report according to ISO 1813 and ISO 9563 is required for the application, it is necessary to inform us of the request for delivery of belts including the certificate when ordering them (when ordering belts via Eshop, please write this request in the "Note" field before by sending the order). The certificate is issued by ContiTech after the test in the production plant.
Documents for Download
Dimensions and Parameters of CONTI SYNCHROFORCE CARBON (EXTREME) Timing Belts
