FS 080 - 32 TB 1210 (Type 2, Cast Iron)
Flat Belt Pulley
Price without VAT: 66.54€
Price including VAT: 80.51€ with VAT
Catalogue price excluding VAT:
67.87€
At supplier, we usually ship within 3 weeks Usual time this product is ready for shipping. Actual availability may vary due to unforeseen circumstances in exceptional cases.
Pulley Parameters
V-pulleys and Poly-V pulleys number of grooves, timing pulleys and sprockets number of teeth.
This standardized product may come from different manufacturers. We will provide you with the currently supplied brand upon request.
Face width.
In the TYMA Product Catalogues you can find this material also described with the abbreviation GG.
Pulley Description
FS 080 - 32 TB 1210 (Type 2, Cast Iron) is a basic type of pulley intended for all types of flat drive belts. It is made from gray cast iron. Its design is based on the DIN 111 standard.
The pulleys are mounted on shafts using the Taper Lock bushes, thanks to which there is not only a fixing on the shaft with a keyway, but also an axial locking against displacement.
Pulley Fields of Use
Flat belt pulleys are designed for all types of flat belts.
They are typically used in compressor drives, pumps, blowers, machine tools, textile machines, the paper, chemical and automotive industries, and many other industries.
Pulley Material
Gray cast iron GG 20 - GG 25.
Other materials on request.
| Parameter | Standard |
|---|---|
| Groove side wobble tolerance | DIN 111 |
| Eccentricity of O/D to bore | DIN 111 |
| Surface roughness | ISO 254 |
| Balance quality grade | VDI 2060, ISO 1940 |
Notice
- Standard catalog pulleys are statically balanced to grade q = 6.3 at 1450 rpm..
- At speeds above 30 m/s, we recommend balancing the pulleys dynamically to grade q = 6.3 and higher.
- At speeds above 42 m/s, pulleys made of C45 steel, ductile iron GGG 40 or other higher quality material must be used.
On request, the pulleys can be balanced dynamically in two planes. Enter this request during the order in the "Note" field in the last step before sending it.
Documents for Download
Dimensions and Parameters of Flat Belt Pulleys for Taper Lock Bushes
TYMA CZ Data Sheets
Czech and English (PDF 847.73 kB)
