32B-2 KÖBO (2” × 1 1/4”, DIN 8187) - 5 m Pack
Roller Chain
Price without VAT: 203.89€
Price including VAT: 246.71€ with VAT
Catalogue price excluding VAT:
208.04€
We sell in a 5 m pack. For easy comparison with alternative products, we present the price per 1 m.
Sale is Over The goods are sold out and their sale has been ended. Therefore, it will not be available in the future, so it cannot be ordered.
Chain Parameters
In the TYMA Product Catalogues you can find this material also described with the abbreviation ST.
Chain Description
32B-2 KÖBO (2” × 1 1/4”, DIN 8187) - 5 m Pack is one of the most common duplex drive chains. It is standardized according to ISO 606 (DIN 8187), meaning it belongs to the European B-series.
The chain consists of outer links with pins and inner links with bushes, on which freely rotating rollers are mounted. The chain is made of steel.
Chain Construction
- Inner link
- Outer link
- Pin
- Bush
- Roller
Chain Fields of Use
32B-2 roller chains according to DIN 8187 are designed for general applications, particularly in heavy industry.
They are primarily used as drive chains but can also be fitted with attachments for material handling and lifting.
Chain Material
Steel.
Documents for Download
Dimensions and Parameters of DIN 8187 Roller Chains
TYMA CZ Data Sheets
Czech and English (PDF 371.93 kB)
